SAE 100 RAT/EN 853 ST 钢丝编织液压软管
LT682
- 应用：适用于输送水基、石油基及可生物降解的液压油。
- 内胶层：黑色耐油合成橡胶
- 增强层：一层或两层编织的高强超柔钢丝
- 外层：黑色耐油、耐天候、耐磨合成橡胶
- 温度范围：-40°C至+100(-40F至+212°F)
详情参数
|
规格 |
软管内径 I.D |
增强层外径 W.D |
软管外径 O.D. |
最大工作压力 . |
试验压力 P.P |
最小爆破压力 Min.B.P.
|
最小弯曲半径 Min.B.R.
|
参考重量 W.T |
|||
| SIZE | 最小 Min |
最大 Max |
最小 Min |
最大 Max |
最小 Min |
最大 Max |
Max.W.P |
||||
| IN | mm | mm | mm | mm | mm | mm | MPa | MPa | MPa | mm | kg/m |
3/16-1 |
4.6 |
5.4 |
9.0 | 10.0 | 11.5 | 12.9 |
25.0 |
50.5 |
100.0 |
90 |
0.18 |
1/4-1 |
6.2 |
7.0 |
10.6 | 11.6 | 14.6 | 16.0 |
22.5 |
45.0 |
90.0 |
100 |
0.27 |
5/16-1 |
7.7 |
8.5 |
12.5 | 13.5 | 16.2 | 17.6 |
21.5 |
43.0 |
85.0 |
115 |
0.33 |
3/8-1 |
9.3 |
10.3 |
14.5 | 15.7 | 18.5 | 19.9 |
18.0 |
36.0 |
72.0 |
130 |
0.40 |
1/2-1 |
12.3 |
13.5 |
17.5 | 19.0 | 21.8 | 23.4 |
16.0 |
32.0 |
64.0 |
180 |
0.50 |
5/8-1 |
15.5 |
16.7 |
20.6 | 22.2 | 24.7 | 26.3 |
13.0 |
26.0 |
52.0 |
200 |
0.58 |
3/4-1 |
18.6 |
19.8 |
24.3 | 25.5 | 28.7 | 30.3 |
10.5 |
21.0 |
42.0 |
240 |
0.73 |
1-1 |
25.0 |
26.4 |
31.9 | 33.1 | 36.3 | 37.9 |
8.8 |
17.5 |
35.0 |
300 |
1.04 |
1 1/4-1 |
31.4 |
33.0 |
39.2 | 40.8 | 43.3 | 45.7 |
6.3 |
15.0 |
25.0 |
420 |
1.28 |
1 1/2-1 |
37.7 |
39.3 |
44.9 | 46.5 | 49.8 | 52.2 |
5.0 |
10.0 |
20.0 |
500 |
1.51 |
2-1 |
50.4 |
52.0 |
58.7 | 60.3 | 64.3 | 66.7 |
4.0 |
8.0 |
16.0 |
630 |
2.20 |
3/16-2 |
4.6 |
5.4 |
10.6 | 11.6 | 14.6 | 16.0 |
41.5 |
83.0 |
165.0 |
90 |
0.33 |
1/4-2 |
6.1 |
7.0 |
12.6 | 13.6 | 16.3 | 17.7 |
40.0 |
80.0 |
160.0 |
100 |
0.42 |
5/16-2 |
7.7 |
8.5 |
14.1 | 15.1 | 18 | 19.4 |
35.0 |
70.0 |
140.0 |
115 |
0.47 |
3/8-2 |
9.3 |
10.3 |
16.3 | 17.5 | 20.3 | 21.7 |
33.0 |
66.0 |
132.0 |
130 |
0.60 |
1/2-2 |
12.3 |
13.5 |
19.4 | 20.6 | 23.4 | 25.0 |
27.5 |
55.0 |
110.0 |
180 |
0.73 |
5/8-2 |
15.5 |
16.7 |
22.2 | 23.8 | 26.6 | 28.2 |
25.0 |
50.0 |
100.0 |
200 |
0.85 |
3/4-2 |
18.6 |
19.8 |
26.2 | 27.8 | 30.6 | 32.2 |
21.5 |
43.0 |
85.0 |
240 |
1.03 |
1-2 |
25.0 |
26.4 |
33.6 | 34.8 | 37.7 | 39.3 |
16.5 |
32.5 |
65.0 |
300 |
1.44 |
1 1/4-2 |
31.4 |
33.0 |
43.6 | 45.0 | 48.0 | 50.4 |
12.5 |
25.0 |
50.0 |
420 |
2.14 |
1 1/2-2 |
37.7 |
39.3 |
49.6 | 51.4 | 54.4 | 56.8 |
9.0 |
18.0 |
36.0 |
500 |
2.50 |
2-2 |
50.4 |
52.0 |
62.3 | 64.7 | 67.0 | 69.4 |
8.0 |
16.0 |
32.0 |
630 |
3.07 |
